Belt Drive Metal Lathes - 22", 10", 10", 1", 23", 50", 19", 6", MT#4, MT#3, 6 3/8"

Belt Drive Metal Lathes – 22″, 10″, 10″, 1″, 23″, 50″, 19″, 6″, MT#4, MT#3, 6 3/8″

SKU 010-LWHE353 Category Brand:

$4,741.80 / Each

Available on backorder

Available on backorder

Add to quote

Description

  • Safety chuck guard automatically shuts lathe off when lifted
  • Includes: 5" 3-jaw chuck, 6 1/2" 4-jaw chuck, replacement gears, 4-way tool post, steady rest, follow rest, 8" face plate, thread chasing dial indicator, MT#3 dead center, full length splash guard, tool box, chuck key and hex keys

Additional information

Weight 163.29312 kg
Dimensions 140.4618984 × 51.561796799999996 × 67.30989840000001 cm
Manufacturer Model

KC-1022ML
Distance Between Centers

22"
Swing Over Bed

10"
Swing Over Gap

10"
Spindle Bore

1"
Overall Width

23"
Overall Length

50"
Overall Height

19"
Swing over cross slide

6"
Taper in headstock

MT#4
Taper in tailstock

MT#3
Total travel of cross slide

6 3/8"
