B&K 1688B Switching DC Power Supply - 240 VAC, 18 VAC, Load (0 to 100% load): ≤50 mV, Line (90 to 132 V AC, 170 to 264 V AC variation): ≤20 mV, Load (10 to 90% rated voltage): ≤100 mA, Line (90 to 132 V AC

B&K 1688B Switching DC Power Supply – 240 VAC, 18 VAC, Load (0 to 100% load): ≤50 mV, Line (90 to 132 V AC, 170 to 264 V AC variation): ≤20 mV, Load (10 to 90% rated voltage): ≤100 mA, Line (90 to 132 V AC

SKU 010-LAM893 Category Brand:

$872.55 / Each

Available on backorder

Available on backorder

Add to quote

Description

  • Automatic CV/CC crossover operation
  • Lightweight and compact
  • Rotary encoder control for precise voltage and current setting
  • Save up to three user-defined voltage and current pre-sets for quick recall
  • PC software for remote control and external timed programming
  • Analog remote control function
  • USB interface
  • Front panel auxiliary output
  • Overvoltage, over temperature, and overload protection

Additional information

Weight 2.3586784 kg
Dimensions 19.812 × 8.8392 × 20.7264 cm
Manufacturer Model

1688B
Input Voltage

240 VAC
Output Voltage

18 VAC
Voltage Regulation

Load (0 to 100% load): ≤50 mV, Line (90 to 132 V AC, 170 to 264 V AC variation): ≤20 mV
Current Regulation

Load (10 to 90% rated voltage): ≤100 mA, Line (90 to 132 V AC, 170 to 264 V AC variation): ≤50 mA
Ripple and Noise

Ripple and noise voltage (rms): ≤5 mV, Ripple and noise voltage (peak-peak): ≤50 mV, Current ripple and noise (rms): ≤30 mA
Meter Type and Accuracy

Voltage/current meter: 3-digit LED display ±0.2% + 3 counts
