FVF-SC2 Datalogging Multimeters

Description

• True-RMS AC voltage and current for accurate measurement on non linear signals
• AC bandwidth specified to 100 kHz
• dBm/dBV
• 50 000-count display with backlight
• Min/Max/Avg and Peak capture
• TrendCapture allows users to graphically review logged readings without needing a PC
• Store up to 10 000 readings with time stamping
• Interval/event logging
• Optically isolated communication port
• IA517 has two terminal 50 Ω range
• Low pass filter
• Low impedance voltage function
• AC/DC voltage range: 50.000 mV to 1000.0 V
• AC/DC current range: 500.00 µA to 10.000 A
• Resistance range: 500.00 Ω to 500.0 MΩ
• Capacitance range: 1.000 nF to 100 mF
• Frequency range: 99.999 Hz to 999.99 kHz
• Temperature range: -200.0 to 1090.0 °C (-328.0 to 1994.0 °F
