KCH Series Chain Hoists – 2200 lbs. (1 tons), 20′, Alloy Steel, ISO 9001-2000 certified factory, ASME B30.16 standards, 64 lb, 11-5/8″, 43′

SKU 010-LXDZ310 Category Lever Chain Hoists Brand: JET

$636.30 / Each

Available on backorder

Description

Professional grade triple spur gear is lightweight and portable
Dual pawl Weston style brake with heavy-duty springs provides safe and reliable operation
Made with premium grade non-asbestos brake discs for long service life
Maintenance free sealed bearings provide easy operation
Load tested to 150% of rated capacity and includes certificate
Heavy-duty ratchet gear protects brake disc from contamination
Made with premium grade 100 heat-treated alloy steel load chain
Top and bottom safety hooks are engineered to bend lowly in case of accidental overload
Made with a hi-viz safety orange finish

Weight	18.393609192 kg
Dimensions	26.12136 × 21.57984 × 24.505920000000003 cm
Manufacturer Model	101116
Capacity	2200 lbs. (1 tons)
Lift	20'
Chain Material	Alloy Steel
Certification	ISO 9001-2000 certified factory, ASME B30.16 standards
Force Required to Lift	64 lb
Head Room	11-5/8"
Length of Hand Chain Pulled to Lift Load to 1'	43'
