KCH Series Chain Hoists – 6600 lbs. (3 tons), 20′, Alloy Steel, ISO 9001-2000 certified factory, ASME B30.16 standards, 79 lb, 20″, 114′

SKU 010-LXDZ323 Category Lever Chain Hoists Brand: JET

$1,318.80 / Each

Available on backorder

Description

Professional grade triple spur gear is lightweight and portable
Dual pawl Weston style brake with heavy-duty springs provides safe and reliable operation
Made with premium grade non-asbestos brake discs for long service life
Maintenance free sealed bearings provide easy operation
Load tested to 150% of rated capacity and includes certificate
Heavy-duty ratchet gear protects brake disc from contamination
Made with premium grade 100 heat-treated alloy steel load chain
Top and bottom safety hooks are engineered to bend lowly in case of accidental overload
Made with a hi-viz safety orange finish

Weight	33.8152836 kg
Dimensions	35.57016 × 22.86 × 28.590239999999998 cm
Manufacturer Model	101146
Capacity	6600 lbs. (3 tons)
Lift	20'
Chain Material	Alloy Steel
Certification	ISO 9001-2000 certified factory, ASME B30.16 standards
Force Required to Lift	79 lb
Head Room	20"
Length of Hand Chain Pulled to Lift Load to 1'	114'
