KCH Series Chain Hoists – 11000 lbs. (5 tons), 10′, Alloy Steel, ASME B30.16 standards, ISO 9001-2000 certified factory, 83 lb, 23-5/8″, 198′

SKU 010-LXDZ324 Category Lever Chain Hoists Brand: JET

$1,604.40 / Each

Available on backorder

Description

Professional grade triple spur gear is lightweight and portable
Dual pawl Weston style brake with heavy-duty springs provides safe and reliable operation
Made with premium grade non-asbestos brake discs for long service life
Maintenance free sealed bearings provide easy operation
Load tested to 150% of rated capacity and includes certificate
Heavy-duty ratchet gear protects brake disc from contamination
Made with premium grade 100 heat-treated alloy steel load chain
Top and bottom safety hooks are engineered to bend lowly in case of accidental overload
Made with a hi-viz safety orange finish

Weight	41.1861536 kg
Dimensions	44.43984 × 24.14016 × 33.00984 cm
Manufacturer Model	101152
Capacity	11000 lbs. (5 tons)
Lift	10'
Chain Material	Alloy Steel
Certification	ASME B30.16 standards, ISO 9001-2000 certified factory
Force Required to Lift	83 lb
Head Room	23-5/8"
Length of Hand Chain Pulled to Lift Load to 1'	198'
